GatEvo ProxPad
Dual-frequency RFID and PIN access — engineered for GatEvo Connect.
Professional-grade outdoor ProxPad reader for gate pillars and post mounts. Read 125 kHz and 13.56 MHz credentials, enforce PIN or two-factor card+PIN, and manage every user from GatEvo Connect over a single RS485 BUS — no protocol converters or secondary controllers.
Trade SKU: GV-PROXPAD-DF
Native RS485 integration. Wire directly to GatEvo Connect on the installer BUS. Credentials, PINs, and schedules are managed in the same platform your clients already use — reducing commissioning time and support callbacks.
Product imagery
High-resolution views for quotations, client packs, and install documentation. Mounting template: 86 × 86 mm footprint.
Flexible authentication modes
Configure per entrance or user group — from simple fob entry to high-security card-plus-PIN for commercial sites.
Card or fob
125 kHz EM or 13.56 MHz MIFARE/NFC presented at the reader.
PIN entry
Backlit keypad with programmable PIN length and lockout policies via Connect.
Card + PIN
Two-factor sequence — credential first, then PIN — for higher-assurance access.
Designed for installer-grade deployments
Dual-frequency reading
One reader head covers legacy 125 kHz estates and modern 13.56 MHz cards — fewer SKUs on the van.
RS485 differential BUS
Reliable communication up to 1,200 m — suited to long driveway runs and noisy environments.
IP65 enclosure
Sealed ABS housing for permanent outdoor mounting in UK weather.
−25 °C to +85 °C
Rated for unheated cabinets and seasonal temperature swings.
Audio & LED feedback
Tri-colour LED and buzzer confirm granted, denied, and PIN-in-progress states.
Sub-200 ms reads
Responsive access without the delay that frustrates users at the gate.
Managed through GatEvo Connect
The ProxPad is a first-class device on the GatEvo BUS. Commission alongside relays and inputs — your client manages day-to-day access in the GatEvo app while you retain installer control via gatevo.net.
- Add, revoke, and schedule credentials without site visits
- Enforce card-only, PIN-only, or combined policies per output
- Pair with GatEvo DIN Rail PSU for a single 12V feed in the cabinet
- Documented RS485 topology for multi-device installs
Technical specifications
| Parameter | Specification |
|---|---|
| Model / SKU | GV-PROXPAD-DF (GatEvo ProxPad) |
| Card frequencies | 125 kHz (EM/HID) + 13.56 MHz (MIFARE, ISO 14443A) |
| Host connection | RS485 BUS — up to 1,200 m |
| Compatible host | GatEvo Connect (RS485 BUS) |
| Power supply | DC 12 V (via GatEvo DIN Rail PSU or approved 12V source) |
| Read distance | Up to 15 cm |
| Operating temperature | −25 °C to +85 °C |
| Enclosure rating | IP65 |
| Mounting footprint | 86 × 86 mm |
| Access modes | Card · PIN · Card + PIN |
| Warranty | 12 months (UK support) |
At a glance
- Frequencies 125 kHz + 13.56 MHz
- Egress rating IP65
- Interface RS485
- Power 12V DC
- Warranty 12 months
Requires GatEvo DIN Rail PSU or equivalent regulated 12V supply when powered from the same enclosure as Connect.
Part of the GatEvo system
Specify controllers, credentials, and power from one trade catalogue — designed to work together inside a single enclosure.
Core smart access controller — Wi-Fi, Ethernet, BLE, and full I/O.
View product
Outdoor dual-frequency RFID reader with PIN — native RS485 to Connect.
Regulated 12V DIN supply for Connect and keypad in one cabinet.
View productFrequently asked questions
Common specification and ordering questions from installers. For wiring diagrams or project-specific advice, contact our UK trade team.
Does the ProxPad work without GatEvo Connect?
Can I use existing 125 kHz fobs from another brand?
What cable should I use for RS485?
Is the ProxPad suitable for gate pillars?
How is power supplied?
