GatEvo DIN Rail PSU
Regulated 12V power for GatEvo controllers and ProxPad — one neat DIN mount.
Ultra-slim switching supply for standard 35 mm DIN rail. Delivers a stable 12V DC output at up to 1.25A — enough to run GatEvo Connect and a GatEvo ProxPad from a single, professional cabinet layout with screw-terminal wiring and built-in protection.
Trade SKU: GV-PSU-DIN-12V
Specification note: This is the GatEvo-branded DIN rail PSU for GatEvo Connect and ProxPad installations. All 4G controller variants and GatEvo ProxPad units require a dedicated 12V PSU. Even for standard non-4G GatEvo Connect installs, a dedicated PSU is still strongly recommended for reliable operation.
Product imagery
Unit photography and wiring diagram for enclosure layout, mains input, and 12V distribution to GatEvo hardware.
Typical cabinet workflow
Designed for the way UK installers already build gate control panels — DIN rail first, then terminations, then device power-up.
Mount on DIN rail
Clip the PSU onto standard 35mm TS-35 rail inside your enclosure. At 17.5mm wide it occupies a single SU — leaving room for Connect and terminations.
Terminate AC & DC
Bring UK mains to the labelled AC screw terminals. Run regulated 12V DC to GatEvo Connect and ProxPad on the output terminals — observe polarity.
Power-up & commission
Energise the panel, confirm 12V under load, then commission Connect and ProxPad on RS485 as per the GatEvo setup guide.
Why installers specify this PSU
Regulated 12V DC
Stable output at up to 1.25A — sized for Connect plus a ProxPad on the same feed.
Ultra-slim DIN mount
17.5mm (1SU) width on 35mm DIN rail — minimal cabinet footprint.
Universal AC input
85–264V AC covers UK 230V mains without dip switches or regional variants.
Built-in protection
Short-circuit, overload, and over-voltage protection for downstream GatEvo hardware.
Fanless design
Silent, maintenance-free convection cooling — no moving parts to fail.
−30 °C to +70 °C
Suitable for unheated outdoor enclosures across UK seasonal temperatures.
Powers the complete GatEvo stack
One PSU in the panel can feed GatEvo Connect and a GatEvo ProxPad together. Screw terminals keep AC input and 12V distribution neat for inspection and future service.
Technical specifications
| Parameter | Specification |
|---|---|
| Model / SKU | GV-PSU-DIN-12V |
| Output voltage | 12V DC (adjustable) |
| Output current | 1.25A maximum |
| Output power | 15W |
| AC input range | 85–264V AC (UK 230V compatible) |
| Efficiency | Up to 87% |
| Mounting | 35mm DIN rail (TS-35) |
| Width | 17.5mm (1SU) |
| Operating temperature | −30 °C to +70 °C |
| Cooling | Fanless — free air convection |
| Protection | Short-circuit · Overload · Over-voltage |
| Connections | Screw terminals (AC L/N/⏚ + DC +/-) |
| Typical load | GatEvo Connect + GatEvo ProxPad |
At a glance
- Output 12V DC
- Current 1.25A max
- Power 15W
- DIN rail 35mm TS-35
- Width 17.5mm
For Connect 4G-only projects, review power options on the Connect 4G product page.
Part of the GatEvo system
Specify controllers, credentials, and power from one trade catalogue — designed to work together inside a single enclosure.
Core smart access controller — Wi-Fi, Ethernet, BLE, and full I/O.
View product
Outdoor dual-frequency RFID reader with PIN — native RS485 to Connect.
View product
Regulated 12V DIN supply for Connect and keypad in one cabinet.
Frequently asked questions
Common specification and ordering questions from installers. For wiring diagrams or project-specific advice, contact our UK trade team.
What does this PSU power?
Is this the same PSU as the Connect 4G bundle?
What mains supply is required?
Can it run in an unheated outdoor cabinet?
How do I size the load?
Order for your next install
Ex-VAT trade pricing for approved installer accounts. Delivery is charged once per order at checkout.
GatEvo DIN Rail PSU
GatEvo DIN Rail PSU
- GatEvo DIN Rail PSU unit
- Screw terminal connections (AC + DC)
- DIN rail clip hardware (as supplied)
